Product Description:
1: The NG Tube is produced by medical grade polyurethane with high biocompatibility, little irritation to body, and strong resistance to acid.
2: Transparent tube facilitates easy observation to the fluid inside, which serves for better tube flush.
3: The NG Tube can be indwelled and maintain for 30 days that can avoid injury due to repeated replacement.
4: The design of protection cap can prevent the food regurgitation which is caused by gastrointestinal contraction under the stimulation of cough, suction, turnover and patting back.
5: Lateral eyes ensures no obstruction inside.
6: Tube with guide wire makes it easy to insert.
7: Radio-opaque line through the length for x-ray visualization.
8: Various specifications are for choice.
Specification:
| Size (FR) | O.D. (mm) | I.D. (mm) | Length (cm) | Guide wire Diameter (mm) |
| 5 | 1.7 | 1 | 50 | 0.7 |
| 5 | 1.7 | 1 | 80 | |
| 5 | 1.7 | 1 | 100 | |
| 5 | 1.7 | 1 | 120 | |
| 5 | 1.7 | 1 | 140 | |
| 6 | 2 | 1 | 50 | |
| 6 | 2 | 1 | 80 | |
| 6 | 2 | 1 | 100 | |
| 6 | 2 | 1 | 120 | |
| 6 | 2 | 1 | 140 | |
| 8 | 2.7 | 1.5 | 50 | |
| 8 | 2.7 | 1.5 | 80 | |
| 8 | 2.7 | 1.5 | 100 | |
| 8 | 2.7 | 1.5 | 120 | |
| 8 | 2.7 | 1.5 | 140 | |
| 10 | 3.3 | 2 | 50 |
1.0 |
| 10 | 3.3 | 2 | 80 | |
| 10 | 3.3 | 2 | 100 | |
| 10 | 3.3 | 2 | 120 | |
| 10 | 3.3 | 2 | 140 | |
| 12 | 4 | 2.7 | 50 | |
| 12 | 4 | 2.7 | 80 | |
| 12 | 4 | 2.7 | 100 | |
| 12 | 4 | 2.7 | 120 | |
| 12 | 4 | 2.7 | 140 | |
| 14 | 4.7 | 3.3 | 50 | |
| 14 | 4.7 | 3.3 | 80 | |
| 14 | 4.7 | 3.3 | 100 | |
| 14 | 4.7 | 3.3 | 120 | |
| 14 | 4.7 | 3.3 | 140 | |
| 16 | 5.3 | 3.8 | 50 | |
| 16 | 5.3 | 3.8 | 80 | |
| 16 | 5.3 | 3.8 | 100 | |
| 16 | 5.3 | 3.8 | 120 | |
| 16 | 5.3 | 3.8 | 140 |
